KOP Series
100% Oil Free Diesel Portable Air Compressor
KOTECH-KOP Series oil free diesel mobile air compressor. 100% oil free Original GHH air end with Diesel engine/ Emissions Stage ll, Stage lllA, Stage V, Tier 4 as required. CE TUV ISO certification.
Perfect choice for power stations, automotive, food, petrochemical and pharmaceuticals industries, as well as in refineries.
Social Sharing:
Introducing our groundbreaking KOP series, the epitome of excellence in the realm of portable compressors. At the forefront is our flagship model, setting new standards for innovation and performance.
Crafted to seamlessly integrate the benefits of a two-stage oil-free compression rotary screw with unparalleled portability, the KOP series is redefining expectations.
KOP Series oil free mobile air compressor specification
Our portable oil-free compression compressors in detail
Model | Diesel Engine | Engine Power KW |
Working Pressure | Air Delivery | |||
Bar | Mpa | Psi | mยณ/min | cfm | |||
KOP-12/8 | QSB4.5-C160 | 119 | 8 | 0.8 | 116 | 12 | 424 |
KOP-17/7 | QSB5.9-C180 | 132 | 7 | 0.7 | 100 | 17 | 600 |
KOP-21/7 | QSB5.9-C180 | 132 | 7 | 0.7 | 100 | 21 | 742 |
KOP-15/10 | QSB5.9-C210 | 154 | 10 | 1.0 | 145 | 15 | 530 |
KOP-27/10.3 | QSL8.9-C325 | 242 | 10.3 | 1.03 | 150 | 27 | 954 |
KOP-38/10.3 | QSZ13-C550 | 410 | 10.3 | 1.03 | 150 | 38 | 1342 |
KOP-42/10 | QSZ13-C550 | 410 | 10 | 1.0 | 145 | 42 | 1483 |
KOP-43/8.6 | QSZ13-C550 | 410 | 8.6 | 0.86 | 125 | 43 | 1518 |
KOP-43/9.3 | QSZ13-C550 | 410 | 9.3 | 0.93 | 135 | 43 | 1518 |
KOP-45/10.3 | QSZ13-C550 | 410 | 10.3 | 1.03 | 150 | 45 | 1589 |
KOP-46/7 | QSZ13-C550 | 410 | 7 | 0.7 | 100 | 46 | 1624 |
KOP-48/8 | QSZ13-C550 | 410 | 8 | 0.8 | 116 | 48 | 1695 |
KOP Series Oil-free Portable Air Compressor Related Industry Applications
