KOA Series

General Feures

Air End

• Gear box
  Horizontal split type for easy maintenance of the bearings and shaft seals.
  Thrust collar instead of thrust bearings. Which makes the structure simpler andincrease the transmission efficiency and reliability.
• Cooler
  Water in tube and air in shell, easy maintenance.
  Variable cross-section patented design is adopted for cooler cabinet.
  Low flow loss and better drainage.
  Patented self-seal structure, easy maintenance and more reliable.
  Super lager design can meet the extreme working condition .
  Allowance for heat recovery design. Which improves the comprehensive utilization efficiency of energy.
• Bearing
  Tilting pad journal bearing realize high-speed and stable operation. Pad tilt will self-adjust when the bearing load changes.
  CC pad of high heat conductivity and high strength can decrease the bearing temperature and promote the stability of the rotor system.
• Diffuser
  The speed energy of air is efficiently converted into pressure energy by the diffuser. Coupled analysis with the impeller provides high efficiency.
  The surface hardness can reach HV1300 for MA treating method is adopted. At the same time the life span of the diffuser will expanded to 3 times.
• Labyrinth Seal
  The gas & oil seal is labyrinth type, which has no contact to the shaft., no abrasion, long life, and low maintenance, no consumption of instrument air, and also, horizontal split makes easier maintenance.
• Inlet Guide Vane
  Smoothly and high efficiency when adjusting.
  More safty and dust proof with cover.
  High reliability by fork type.

High Efficiency Scroll

Revolute Design

Involute Design

The gas will enter the scroll directly for revolute type, but one vertical retrace will occur for involute type .
The efficiency is increased by 2%.

Patented High Efficiency And High Reliability Cooler

• High efficiency & reliability design
  1. Straight tube design, no need to be pull out when maintaining,90% maintenance time saved.
  2. No consumption parts and low maintenance fee.
  3. Larger design, high heat exchange efficiency, low water consumption and low pressure loss, about 1-2% energy saving.
  4. Gradual changing Cross design, perfect gas-liquid separation effect.
  5. Stainless steel backing board design, eliminating corrosion risk.
  6. No fastening parts, no risk of dameging the impellor by fallen parts.
  7. Supported by both side, eliminating the damage risk from resonance.
  8. Long life span drainer, no rusty, draining strongly and zero gas consumption.
• Patented compact design for air & oil cooler
  1. Compact structure, short piping and easy install.
  2. Inlet water pressure is the same for oil and air cooling.

The Complete Solution

High reliability, high safety and enviromental protection.
Energy saving.
Integrated package and economical installation.
Siemens PLC + touch screen, friendly interface and easy operation.
Easy maintenance and economical cost.
1-4 stage option.
No instrument gas required.
No special base and anchor bolt required.
Oil-free.
Silicon-free.
No sealing gas required.
Low noise and low vibration.
Anti surge protection.
